Metallurgy Industry Graphite Gold Bar Mold Graphite Metal Molds Abrasion Resistance

Metallurgy Industry Graphite Gold Bar Mold Graphite Metal Molds Abrasion Resistance
Metallurgy Industry Graphite Gold Bar Mold Graphite Metal Molds Abrasion Resistance Metallurgy Industry Graphite Gold Bar Mold Graphite Metal Molds Abrasion Resistance Metallurgy Industry Graphite Gold Bar Mold Graphite Metal Molds Abrasion Resistance Metallurgy Industry Graphite Gold Bar Mold Graphite Metal Molds Abrasion Resistance

Large Image :  Metallurgy Industry Graphite Gold Bar Mold Graphite Metal Molds Abrasion Resistance

Product Details:
Place of Origin: China
Brand Name: Haicheng
Certification: ISO9001, ISO14000, IATF16949
Model Number: M120P
Payment & Shipping Terms:
Minimum Order Quantity: 10 pcs
Price: Negotiable
Packaging Details: Carton box
Delivery Time: 15-20 days
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 200000 pcs per month

Metallurgy Industry Graphite Gold Bar Mold Graphite Metal Molds Abrasion Resistance

Description
Materials: Antimony Graphite,isostatic Graphite Temperature Resistance Resistance: 200-650℃
Application: Metallurgy Industry Flexural Strength: 20- 45 Mpa Different Grades Available
Lead Time: 25-30 Days Chemical Composition: High Purity Graphite, Carbon>99%
High Light:

Metallurgy Industry Graphite Gold Bar Mold

,

Metallurgy Industry Graphite Metal Molds

,

Graphite Metal Molds Abrasion Resistance

Custom Carbon Graphite Molds For Gold Melting Various Sizes Supply



Graphite mould advantage:

1. Excellent thermal conductivity and conductive properties

2. Low coefficient of linear expansion coefficient and good thermal stability and thermal shock resistance

3. Chemical corrosion is not easy to react with most metals

4. The strength increases with the increase of temperature at high temperature (more than 800 in the sintering temperature of the copper matrix)High temperature resistance

5. Good lubrication and abrasion resistance

6. Factory supply customized graphite sintering mould and high precision mold



Company Brief introduction
Year Established :2005
Location: Zigong City, Sichuan Province, China
Covering Area: Over 3000 squire meters
Employees:200
No of production lines: 10
Total Annual Revenue: USD 30 Millions





Material proformance



Model Impregnation Origin Density Compressive(Mpa) Flexural(Mpa) Shore Hardness(HSD) Temperature Limit(°)
M106K Resin China 1.72 175 55 75 200
M120D Antimony China 2.2 145 50 70 500
M120P Copper China 2.2 220 65 60 400
M254K Resin China 1.7 80 38 45 200
M254D Antimony China 2 65 35 35 500
M120R Glass China 1.9 190 60 100 600
KC673 Resin Japan 1.87 240 78 87 200
KC573 Resin Japan 1.85 370 85 110 200
KC5709 Antimony Japan 2.25 430 100 115 500


Metallurgy Industry Graphite Gold Bar Mold Graphite Metal Molds Abrasion Resistance 0Metallurgy Industry Graphite Gold Bar Mold Graphite Metal Molds Abrasion Resistance 1

Metallurgy Industry Graphite Gold Bar Mold Graphite Metal Molds Abrasion Resistance 2









FQA



Q1:Are you a manufacturing factory or a trading company?

A1: We are professional manufacturer for graphite products. we supply various kinds of graphite products.

Q2: What's your MOQ?
A2: No limit to the quantity.

Q3: What's your lead time for production?
A3: The lead time for normal products is 25-30 days. it need to be negotiated for special cases.

Q4: Can I have a sample order?
A4: Yes, we welcome sample order for checking quality, it will be free for our stock sample, but the delivery charge will on your expense.


Q5: Do you have stock products to sell?

A5: No,We produce these products accorded to the customer’s requirement,It also means material, density, shape, size,design,quantity will depend on what your need.OEM orders always be welcomed.
